Supachok Flanges, a well-respected manufacturer and supplier based in Bangkok, Thailand, specializes in high-quality **ANSI B16.47 Flanges** that are perfect for large-diameter and high-pressure piping applications. Crafted to meet stringent international standards, these flanges are built to last, offering exceptional durability, strength, and leak-proof connections for critical operations. Supachok Flanges utilizes cutting-edge technology, premium materials, and thorough quality testing to guarantee reliable performance across various industries. Renowned for their outstanding resistance to corrosion and mechanical stress, ANSI B16.47 Flanges are a trusted choice in the oil and gas, petrochemical, marine, and power sectors, making them ideal for demanding industrial environments that require robust and efficient solutions.
These flanges are made from carbon steel, alloy steel, and stainless steel, enhanced with alloying elements like chromium, molybdenum, and nickel to boost their corrosion resistance and strength. They feature high tensile and yield strength, excellent toughness, and dependable hardness, making them suitable for large-diameter, high-pressure systems. Their mechanical properties include resistance to stress corrosion cracking, pitting, and oxidation, ensuring long-lasting durability. With great weldability, ductility, and precise dimensions, these flanges promise reliable performance in heavy-duty industrial piping applications.
Supachok Flanges, a premier supplier in Bangkok, Thailand, specializes in high-quality ANSI B16.47 Flanges, valued for their exceptional durability, corrosion resistance, precise engineering, and suitability across diverse industrial applications.
| pecifications | ANSI 16.47 Flanges |
|---|---|
| ANSI 16.47 Flange size range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Main Types | Forged / Threaded / Screwed / Plate |
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
| Production technique | Forged, Heat treated and machined |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS JIS Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange |
| Specialized manufacturer of | DIN 2566 en 1092 1 Pn16 Flange DIN 2566 pn16 Rtj Flange ANSI 16.47 Sorf Flange ANSI 16.47 Table Flanges DIN 2566 pn10 ANSI 16.47 Large Diameter Flange ANSI 16.47 Threaded Flanges ANSI 16.47 Blind Flanges ANSI 16.47 Plate Flanges ANSI 16.47 Weld Neck Flanges ANSI 16.47 Loose Flanges ANSI 16.47 Orifice Flanges ANSI 16.47 Slip-On Flanges ANSI 16.47 Lap Joint Flanges ANSI 16.47 Socketweld Flanges ANSI 16.47 AS 4087 Water Flanges |
| Test | Hydrostatic testing machine, Direct-reading Spectrograph,UI trasonic flaw detector, X-ray detector, Magnetic particle detector |
| Equipment | Bending machine, Press machine, electric bevelling machine, Pushing Machine, Sand-blasting machine etc |
| Origin | West Europe /Indian / USA / Japan / Korean |
| Key markets and industries for ANSI B16.47 Flange | Nuclear power (mostly seamless). Heavy oil refineries. Bitumen upgraders. Petrochemicals and acids. |
| Export to | Indonesia, Ireland, Ukraine, Singapore,Saudi Arabia,Canada, Peru, Dubai, Brazil, Iran, Korea, USA, India, Egypt, Thailand, Spain, Oman etc |
| ANSI B16.47 Flanges Application | To Connect Pipe & Tubes in Power, Petroleum,Construction, Chemical, Gas, Shipbuilding,Metallurgy, etc |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| Nominal Size | Outside Diameter (OD) | Min. Thickness [Note1] – WNF (tf) | Min. Thickness [Note1] – Blind (tf) | Length Through Hub (Y) | Hub Dia. Base [Note2] (X) | Hub Dia. Top (A) | Raised Face Dia. (R) | Drilling – Bolt Circle Dia. | Drilling- No. of Bolt Holes | Drilling – Dia. of Bolt Hole | Dia. of Bolt | Min. Fillet Radius (r1) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 26 | 38.25 | 3.50 | 3.88 | 7.62 | 28.62 | 26.00 | 29.50 | 34.50 | 28 | 178 | 134 | 0.44 |
| 28 | 40.75 | 3.75 | 4.12 | 8.12 | 30.81 | 28.00 | 31.50 | 37.00 | 28 | 2 | 178 | 0.50 |
| 30 | 43.00 | 4.00 | 4.38 | 8.62 | 32.94 | 30.00 | 33.75 | 39.25 | 28 | 218 | 2 | 0.50 |
| 32 | 45.25 | 4.25 | 4.56 | 9.12 | 35.00 | 32.00 | 36.00 | 41.50 | 28 | 218 | 2 | 0.50 |
| 34 | 47.50 | 4.38 | 4.81 | 9.50 | 37.19 | 34.00 | 38.00 | 43.50 | 28 | 218 | 2 | 0.56 |
| 36 | 50.00 | 4.50 | 5.06 | 9.88 | 39.38 | 36.00 | 40.25 | 46.00 | 32 | 218 | 2 | 0.56 |
| 38 | 47.50 | 4.88 | 4.88 | 8.12 | 39.50 | 38.00 | 40.75 | 44.00 | 32 | 178 | 134 | 0.56 |
| 40 | 50.00 | 5.12 | 5.12 | 8.50 | 41.50 | 40.00 | 43.00 | 46.25 | 32 | 2 | 178 | 0.56 |
| 42 | 52.00 | 5.25 | 5.25 | 8.81 | 43.62 | 42.00 | 45.00 | 48.25 | 32 | 2 | 178 | 0.56 |
| 44 | 54.50 | 5.50 | 5.50 | 9.18 | 45.62 | 44.00 | 47.25 | 50.50 | 32 | 218 | 2 | 0.56 |
| 46 | 56.75 | 5.75 | 5.75 | 9.62 | 47.75 | 46.00 | 49.50 | 52.75 | 36 | 218 | 2 | 0.56 |
| 48 | 59.50 | 6.00 | 6.00 | 10.12 | 49.88 | 48.00 | 51.50 | 55.25 | 28 | 238 | 214 | 0.56 |
| 50 | 61.75 | 6.19 | 6.25 | 10.56 | 52.00 | 50.00 | 53.62 | 57.50 | 32 | 238 | 214 | 0.56 |
| 52 | 63.75 | 6.38 | 6.44 | 10.88 | 54.00 | 52.00 | 55.62 | 59.50 | 32 | 238 | 214 | 0.56 |
| 54 | 67.00 | 6.69 | 6.75 | 11.38 | 56.12 | 54.00 | 57.88 | 62.25 | 28 | 258 | 212 | 0.56 |
| 56 | 69.00 | 6.88 | 6.94 | 11.75 | 58.25 | 56.00 | 60.12 | 64.25 | 32 | 258 | 212 | 0.56 |
| 58 | 71.00 | 7.00 | 7.12 | 12.06 | 60.25 | 58.00 | 62.12 | 66.25 | 32 | 258 | 212 | 0.56 |
| 60 | 74.25 | 7.31 | 7.44 | 12.56 | 62.38 | 60.00 | 64.38 | 69.00 | 32 | 278 | 234 | 0.56 |
ANSI B16.47 Flanges are widely used in industries that require large-diameter and high-pressure connections. They play a crucial role in oil and gas pipelines, offshore drilling platforms, petrochemical plants, chemical processing, and power generation systems. Their sturdy design and superior sealing capabilities make them perfect for connecting pumps, valves, storage tanks, and heat exchangers. In marine and offshore settings, they offer excellent corrosion resistance against harsh conditions. ANSI B16.47 Flanges ensure safe and leak-proof operations, providing efficiency, durability, and a long service life in critical industrial applications.
Yes, we offer custom sizes for ANSI B16.47 Flanges to meet specific project needs. Our team at Supachok Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@supachokflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
