DIN 2631 PN6 Weld Neck Flanges Manufacturer and Supplier in Bangkok, Thailand

Supachok Flanges, a reputable manufacturer and supplier based in Bangkok, Thailand, specializes in top-notch DIN 2631 PN6 Weld Neck Flanges. These flanges are crafted for strength, durability, and leak-proof performance, making them perfect for low-pressure piping systems. With a long tapered hub, they ensure smooth stress distribution, which is key for safe and reliable operation. Adhering strictly to DIN standards, these flanges are the go-to choice for pipelines that need permanent, high-integrity joints. Supachok Flanges prides itself on delivering precision-engineered, cost-effective solutions that find their place in various industries, including water treatment, chemicals, marine, HVAC, and power, all while guaranteeing long service life, safety, and efficiency in critical operations.

DIN 2631 PN6 Standards Weld Neck Flanges in Bangkok, DIN 2631 PN6 Weld Neck Plate Flange in Pattaya, Raised Face DIN 2631 PN6 WNRF Flanges in Rayong, Stainless Steel DIN 2631 PN6 Weld Neck Flanges in Nonthaburi, DIN 2631 PN6 Welding Neck Pipe Flange in Chiang Mai, Best Price of DIN 2631 PN6 Weld Neck Flange Manufacturer in Thailand.

Stainless Steel DIN 2631 PN6 Weld Neck Flanges

Alloy Steel DIN 2631 PN6 Weld Neck Flanges

Alloy 20 DIN 2631 PN6 Weld Neck Flanges

Made from high-quality carbon steel, stainless steel, or alloy steel, DIN 2631 PN6 Weld Neck Flanges offer impressive strength, corrosion resistance, and durability for low-pressure applications. Their material composition allows them to withstand mild chemicals, seawater, and temperature changes. On the mechanical side, these flanges boast excellent tensile and yield strength, toughness, and fatigue resistance, ensuring they perform reliably. The weld neck design enhances structural integrity by minimizing stress concentration at the flange’s base. Combining mechanical stability with corrosion resistance, DIN 2631 PN6 Weld Neck Flanges are a dependable choice for low-pressure piping systems.

Monel DIN 2631 PN6 WNRF Flange in Thailand, Hastelloy DIN 2631 PN6 Weld Neck Flanges in Bangkok, Titanium DIN 2631 PN6 Welding Neck Flanges in Chiang Mai, SS DIN 2631 PN6 Weld Neck Flanges Stockist in Pattaya, Nickel Alloy DIN 2631 PN6 Weld Neck Flanges in Rayong, Inconel DIN 2631 PN6 WNRF Flanges in Nonthaburi, Alloy Steel DIN 2631 PN6 Weld Neck Flanges, Duplex Steel DIN 2631 Weld Neck Flange, Carbon Steel DIN 2631 PN6 Welding Neck Flanges in Thailand.

DIN 2631 PN6 Weld Neck Flanges Specification

Size Chart	1/2″ (15 NB) To 48″ (1200NB)
Coating Flanges Faces	Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint
Design For Size	DIN, EN, ASA, PN, JIS, BS, ANSI, ASME
Pressure Rating Table	Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS
Supporting Flanges Material	Flanges Bolts, Gasket, Ring Joint
Connect Type Type	FF, RTJ, SMF, LMF, RF, LJF
Production Process	Forged, Heat Treated and Machined
Standard	ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange
Machining Equipment	Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc

DIN 2631 PN6 Weld Neck Flange Dimensions

Pipe			Flange				Neck				Raised face		Screws			Weight
Pipe			Flange				Neck				Raised face		Screws			(7,85 Kg/dm3)
Rated	d1		D	b	k	h1	d3	s	r	h2	d4	f	Holes	Thread	d2	Kg
Diameter	ISO Series	DIN Series	D	b	k	h1	d3	s	r	h2	d4	f	Holes	Thread	d2	Kg
15	–	20	80	12	55	30	28	2	4	6	40	2	4	M 10	11	0,392
15	21,3	–	80	12	55	30	30	2	4	6	40	2	4	M 10	11	0,392
20	–	25	90	14	65	32	35	2,3	4	6	50	2	4	M 10	11	0,592
20	26,9	–	90	14	65	32	38	2,3	4	6	50	2	4	M 10	11	0,592
25	–	30	100	14	75	35	40	2,6	4	6	60	2	4	M 10	11	0,747
25	33,7	–	100	14	75	35	42	2,6	4	6	60	2	4	M 10	11	0,747
32	–	38	120	14	90	35	50	2,6	6	6	70	2	4	M 12	14	1,05
32	42,4	–	120	14	90	35	55	2,6	6	6	70	2	4	M 12	14	1,05
40	–	44,5	130	14	100	38	58	2,6	6	7	80	3	4	M 12	14	1,18
40	48,3	–	130	14	100	38	62	2,6	6	7	80	3	4	M 12	14	1,18
50	–	57	140	14	110	38	70	2,9	6	8	90	3	4	M 12	14	1,34
50	60,3	–	140	14	110	38	74	2,9	6	8	90	3	4	M 12	14	1,34
65	76,1	–	160	14	130	38	88	2,9	6	9	110	3	4	M 12	14	1,67
80	88,9	–	190	16	150	42	102	3,2	8	10	128	3	4	M 16	18	2,71
100	–	108	210	16	170	45	122	3,6	8	10	148	3	4	M 16	18	3,24
100	114,3		210	16	170	45	130	3,6	8	10	148	3	4	M 16	18	3,24
125	–	133	240	18	200	48	148	4	8	10	178	3	8	M 16	18	4,49
125	139,7	–	240	18	200	48	155	4	8	10	178	3	8	M 16	18	4,49
150	–	159	265	18	225	48	172	4,5	10	12	202	3	8	M 16	18	5,15
150	168,3	–	265	18	225	48	184	4,5	10	12	202	3	8	M 16	18	5,15
200	219,1	–	320	20	280	55	236	5,9	10	15	258	3	8	M 16	18	7,78
250	–	267	375	22	335	60	282	6,3	12	15	312	3	12	M 16	18	10,8
250	273	–	375	22	335	60	290	6,3	12	15	312	3	12	M 16	18	10,8
300	323,9	–	440	22	395	62	342	7,1	15	15	365	4	12	M 20	22	14
350	355,6	–	490	22	445	62	385	7,1	12	15	415	4	12	M 20	22	18,5
350	–	368	490	22	445	62	385	7,1	12	15	415	4	12	M 20	22	16,7
400	406,4	–	540	22	495	65	438	7,1	12	15	465	4	16	M 20	22	21,2
400	–	419	540	22	495	65	438	7,1	12	15	465	4	16	M 20	22	19
500	508	–	645	24	600	68	538	7,1	12	15	570	4	20	M 20	22	28,6
600	610	–	755	24	705	70	640	7,1	12	16	670	5	20	M 24	26	31,5
700	711	–	860	24	810	70	740	7,1	12	16	775	5	24	M 24	26	37,4
800	813	–	975	24	920	70	842	7,1	12	16	880	5	24	M 27	30	46,1
900	914	–	1075	26	1020	70	942	7,1	12	16	980	5	24	M 27	30	55,6
1000	1016	–	1175	26	1120	70	1045	7,1	16	16	1080	5	28	M 27	30	61,9

Largest DIN 2631 PN6 Weld Neck Flanges Supplier in Bangkok, Thailand

Supachok Flanges, a leading supplier in Bangkok, Thailand, offers an extensive selection of DIN 2631 PN6 Weld Neck Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.

Contact us to get a quick quote for your requirement.

We offer These Flanges as per DIN, ISO, JIS or ANSI Standard.

These flanges are widely utilized in low-pressure piping systems where strong, permanent, and leak-proof connections are essential. You’ll often find them in water supply and wastewater treatment plants, as well as in chemical and petrochemical processing and HVAC systems. The marine industry also makes use of them in non-critical seawater pipelines and auxiliary systems. Power generation facilities rely on them for low-pressure cooling water lines and auxiliary circuits. Thanks to their robust weld neck design, corrosion resistance, and long service life, DIN 2631 PN6 Weld Neck Flanges ensure efficient, safe, and cost-effective operations.

DIN 2631 PN6 Welding Neck Flanges Stockist in Chiang Mai, DIN 2631 PN6 Weld Neck Flanges Supplier in Pattaya, DIN 2631 PN6 Weld Neck Flanges Supplier in Bangkok, DIN 2631 PN6 Welding Neck Flanges Stockist in Thailand, DIN 2631 PN6 Weld Neck Flanges Manufacturer in MM, DIN 2631 PN6 WNRF Flanges Manufacturer in Thailand.

Types of DIN 2631 PN6 Weld Neck Flanges

Are Custom Sizes Available for DIN 2631 PN6 Weld Neck Flanges?

Yes, we offer custom sizes for DIN 2631 PN6 Weld Neck Flanges to meet specific project needs. Our team at Supachok Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@supachokflanges.com.

DIN 2631 PN6 Weld Neck Plate Flange Size Chart

NPS NPS (inch)
NPS NPS (inch)	Diammeter of Flange (inch)	No. of Bolts	Diammeter of Bolts (inch)	Diammeter of Bolt Holes (inch)	Bolt Circle (inch)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Widest Range of DIN 2631 PN6 Weld Neck Flanges in Thailand.

Nickel Alloy DIN 2631 PN6 Welding Neck Flange	Mild Steel DIN 2631 PN6 Weld Neck Flange
Carbon Steel DIN 2631 PN6 Welding Neck Flange	DIN 2631 PN6 Weld Neck RF Flange Supplier in Thailand
DIN 2631 PN6 Weld Neck Flange Dimensions	Raised Face DIN 2631 PN6 Weld Neck Flange Manufacturer
18 inch DIN 2631 PN6 Carbon Steel Weld Neck Flange	DIN 2631 PN6 Weld Neck Flange Dimensions in mm
Alloy Steel DIN 2631 PN6 Welding Neck Flanges	Copper Nickel DIN 2631 PN6 Weld Neck Flanges at Best Price
DIN 2631 PN6 Welding Neck FF Flange Supplier	Suppliers of DIN 2631 PN6 Weld Neck Flange
German Standard DIN 2631 PN6 Weld Neck Flanges	DIN 2631 PN6 Weld Neck Flange Supplier in Thailand
DIN 2631 PN6 Weld Neck Flange Manufacturer	Flat Face DIN 2631 PN6 Weld Neck Flange Manufacturer
DIN 2631 PN6 WNRF Flange Stockist in Thailand	Raised Faced DIN 2631 PN6 welding-neck flanges Dealer in Thailand
Stainless Steel DIN 2631 PN6 Weld Neck Flange	ASTM B564 Raised Faced DIN 2631 PN6 Weld Neck Flanges
DIN 2631 PN6 WNRF Flange Exporter	DIN 2631 PN6 Weld Neck Flange Pressure Ratings
Raised Face DIN 2631 PN6 Weld Neck Plate Flanges	Titanium DIN 2631 PN6 Welding Neck Flanges
DIN 2631 PN6 WNRF Flanges Supplier in Pattaya	Alloy Steel DIN 2631 PN6 Weld Neck Flanges Manufacturer in Thailand
DIN 2631 PN6 Weld Neck Pipe Flanges Supplier in Chiang Mai	Duplex Steel DIN 2631 PN6 Weld Neck Flanges
4 inch Stainless Steel DIN 2631 PN6 Weld Neck Flange	DIN 2631 PN6 Weld Neck RF Flanges Stockholder
DIN 2631 PN6 Welding Neck Flanges Supplier in Bangkok	MS DIN 2631 PN6 Weld Neck Flange
30 inch DIN 2631 PN6 Weld Neck Flange Dealer	Raised Face DIN 2631 PN6 Weld Neck Flanges Manufacturer
8 Inch DIN 2631 PN6 Welding Neck Pipe Flanges	DIN 2631 PN6 Weld Neck Flanges Stockist
Carbon Steel Raised Face DIN 2631 PN6 Weld Neck Flange Stockist	Duplex Steel DIN 2631 PN6 WNRF Flanges Supplier in Bangkok
ASME SA105N Raised Faced DIN 2631 PN6 Weld Neck Flanges	18 inch Carbon Steel DIN 2631 PN6 Weld Neck Flange
DIN 2631 PN6 Weld Neck Pipe Flanges Wholesaler	DIN 2631 PN6 WNRF Flanges Supplier
DIN 2631 PN6 Large Diameter Weld Neck Flange	30 Inch DIN 2631 PN6 Weld Neck Pipe Flange Dimensions
DIN 2631 PN6 WNRF Flanges Distributor in Bangkok	Flat Face DIN 2631 PN6 Weld Neck Flanges Exporter

Material Testing

We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
