Supachok Flanges, based in Bangkok, Thailand, stands out as a top manufacturer and supplier of high-quality DIN 2566 PN16 Threaded Flanges. These flanges are crafted for reliability, corrosion resistance, and easy installation. With their internal threading, they allow for pipe connections without the need for welding, making them perfect for medium-pressure systems and applications that require frequent assembly or maintenance. Adhering to strict DIN standards, these flanges ensure secure, leak-proof connections across various industrial environments. Supachok Flanges is known for delivering cost-effective, precision-engineered solutions that are trusted in industries like marine, chemical, petrochemical, water treatment, HVAC, and power generation, all aimed at promoting efficient and safe operations.
Typically made from high-quality carbon steel, stainless steel, or alloy steel, DIN 2566 PN16 Threaded Flanges offer the strength, durability, and corrosion resistance needed for medium-pressure applications. Their material composition guarantees reliable performance even when exposed to chemicals, seawater, and moderate temperature changes. On a mechanical level, these flanges provide excellent tensile and yield strength, toughness, and resistance to fatigue. The threaded design simplifies installation and removal without welding, ensuring secure, leak-proof joints. By combining mechanical strength with corrosion resistance, DIN 2566 PN16 Threaded Flanges are ideal for medium-pressure piping systems in industrial, marine, and chemical settings.
| Size Chart | 1/2″ (15 NB) To 48″ (1200NB) |
| Coating Flanges Faces | Zinc Plated, Oil Black Paint, Yellow Transparent, Cold and Hot Dip Galvanized, Anti-rust Paint |
| Design For Size | DIN, EN, ASA, PN, JIS, BS, ANSI, ASME |
| Pressure Rating Table | Class 150 LBS, Class 300 LBS, Class 600 LBS, Class 900 LBS, Class 1500 LBS, Class 2500 LBS |
| Supporting Flanges Material | Flanges Bolts, Gasket, Ring Joint |
| Connect Type Type | FF, RTJ, SMF, LMF, RF, LJF |
| Production Process | Forged, Heat Treated and Machined |
| Standard | ASME B16.38 Flange, DIN Flange, ISO Flange, JIS Flange, PN Flange, MSS SP44 Flange, EN-1092 Flange, BS10 Flange, ASME B16.47 (Series A, Series B) Flange, UNI Flange, ASME B16.5 Flange, AWWA Flange, DIN Flange, GOST Flange |
| Machining Equipment | Bending machine, Sand-blasting machine, Press machine, Pushing Machine, Electric bevelling machine etc |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | D | b | k | h1 | d3 | d4 | f | Holes | Thread | d2 | Kg | |
| 15 | 21,3 | R 1/2 | 95 | 14 | 65 | 20 | 35 | 45 | 2 | 4 | M 12 | 14 | 0,613 |
| 20 | 26,9 | R 3/4 | 105 | 16 | 75 | 24 | 45 | 58 | 2 | 4 | M 12 | 14 | 0,91 |
| 25 | 33,7 | R 1 | 115 | 16 | 85 | 24 | 52 | 68 | 2 | 4 | M 12 | 14 | 1,1 |
| 32 | 42,4 | R 1 1/4 | 140 | 16 | 100 | 26 | 60 | 78 | 2 | 4 | M 16 | 18 | 1,6 |
| 40 | 48,3 | R 1 1/2 | 150 | 16 | 110 | 26 | 70 | 88 | 3 | 4 | M 16 | 18 | 1,78 |
| 50 | 60,3 | R 2 | 165 | 18 | 125 | 28 | 85 | 102 | 3 | 4 | M 16 | 18 | 2,43 |
| 65 | 76,1 | R 2 1/2 | 185 | 18 | 145 | 32 | 105 | 122 | 3 | 4 | M 16 | 18 | 3,18 |
| 80 | 88,9 | R 3 | 200 | 20 | 160 | 34 | 118 | 138 | 3 | 8 | M 16 | 18 | 4,12 |
| 100 | 114,3 | R 4 | 220 | 20 | 180 | 38 | 140 | 158 | 3 | 8 | M 16 | 18 | 4,47 |
| 125 | 139,7 | R 5 | 250 | 22 | 210 | 40 | 168 | 188 | 3 | 8 | M 16 | 18 | 6,13 |
| 150 | 165,1 | R 6 | 285 | 22 | 240 | 44 | 195 | 212 | 3 | 8 | M 20 | 22 | 7,92 |
Supachok Flanges, a leading supplier in Bangkok, Thailand, offers an extensive selection of DIN 2566 PN16 Threaded Flanges , including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
These flanges are widely utilized in industries that demand strong, corrosion-resistant, and easily installed medium-pressure pipeline connections. You’ll find them commonly used in water treatment plants, HVAC systems, and the chemical and petrochemical sectors, as well as in marine pipelines. Power generation facilities rely on them for cooling water systems, heat exchangers, and auxiliary piping. The oil and gas industries also favor these flanges for medium-pressure fluid transmission, especially where welding isn’t the preferred option. Thanks to their straightforward installation, reliable sealing, and robust performance, DIN 2566 PN16 Threaded Flanges are a go-to choice for many applications.
Yes, we offer custom sizes for DIN 2566 PN16 Threaded Flanges to meet specific project needs. Our team at Supachok Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@supachokflanges.com.
