Supachok Flanges, a well-respected manufacturer and supplier located in Bangkok, Thailand, has built a solid reputation for providing top-notch Hastelloy C276 flanges that meet the demanding needs of various industries. With a focus on precision engineering, cutting-edge technology, and a commitment to global standards, Supachok Flanges guarantees exceptional durability, performance, and resistance even in the toughest environments. Their Hastelloy C276 flanges are specifically crafted to endure extreme chemical, thermal, and mechanical conditions, making them a reliable choice for industries that prioritize safety and efficiency. Catering to sectors like chemical, petrochemical, marine, and pharmaceutical, Supachok Flanges offers tailored solutions that clients around the globe trust for lasting performance.
Hastelloy C276 flanges are primarily made up of nickel, molybdenum, and chromium, with added elements like tungsten, iron, and cobalt, which provide outstanding resistance to both oxidizing and reducing agents. These flanges boast impressive tensile strength, toughness, and ductility, even at high temperatures. Their mechanical properties help them resist pitting, crevice corrosion, and stress-corrosion cracking. Hastelloy C276 flanges maintain their stability during thermal cycling and under significant mechanical stress, making them perfect for demanding environments. The unique combination of their composition and mechanical strength ensures reliable, long-term service in critical industrial applications.
| C276 Forged Fittings Specifications | ASTM B564/ ASME SB564 |
|---|---|
| C276 Alloy Forged Fittings size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Hastelloy C276 Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Hastelloy C276 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM B564 C276 Hastelloy Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Hastelloy C276 Forged Fittings Thread | NPT, BSPT, BSPP |
| C276 Hastelloy Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Nickel Alloy C276 Forged Fittings Origin & Mills | Thailand |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Supachok Flanges, a leading supplier in Bangkok, Thailand, offers an extensive selection of Hastelloy C276 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
These flanges are commonly found in chemical processing plants, petrochemical refineries, marine applications, and pharmaceutical manufacturing facilities, thanks to their remarkable corrosion resistance. They excel in systems that handle aggressive chemicals like hydrochloric acid, sulfuric acid, chlorine, and seawater. You’ll find these flanges in piping systems, reactors, pressure vessels, and heat exchangers, where strong and leak-proof connections are essential. Their ability to perform in high-temperature and corrosive settings guarantees operational safety and efficiency across various industries.
| ASTM B564 / B564M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Hastelloy Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Hastelloy fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
Yes, we offer custom sizes for Hastelloy C276 Flanges to meet specific project needs. Our team at Supachok Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@supachokflanges.com.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | OR | GOST |
| Hastelloy C276 | N10276 | 2.4819 | – | NiMo16Cr15W | NW 0276 | ЭП760 | ХН65МВУ |
| Grade | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V | Ni |
| C276 | 0.01 | 15.0 – 17.0 | 1.0 | 0.08 | 4.00 – 7.00 | 0.04 | 0.03 | 2.5 | 14.5 – 16.5 | 3 – 4.5 | 0.35 | Bal |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | Psi – 1,15,000 , MPa – 790 | 40 % |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
