Supachok Flanges, a leading manufacturer and supplier located in Bangkok, Thailand, is all about crafting top-notch Hastelloy C22 flanges designed for tough industrial applications. Renowned for their precision engineering and commitment to international standards, Supachok Flanges delivers flanges that stand out for their incredible durability, resistance to corrosion, and reliable performance even in extreme conditions. Their Hastelloy C22 flanges are a go-to choice in the chemical, petrochemical, pharmaceutical, and marine sectors, expertly handling aggressive environments and high-temperature operations. With a strong emphasis on reliability and tailored solutions, Supachok Flanges makes sure clients get products that fit their exact needs while upholding the highest safety and operational efficiency standards.
Hastelloy C22 flanges are primarily made up of nickel, chromium, molybdenum, and tungsten, along with trace amounts of iron, cobalt, and manganese, which give them remarkable resistance to both oxidizing and reducing agents. They boast impressive mechanical properties, such as high tensile strength, exceptional toughness, and great ductility at elevated temperatures. These flanges are particularly resistant to pitting, crevice corrosion, and stress-corrosion cracking, making them perfect for harsh chemical environments. Their ability to maintain structural integrity during thermal cycling and mechanical stress guarantees long-lasting performance in critical applications where standard alloys might not hold up.
| C22 Forged Fittings Specifications | ASTM B564/ ASME SB564 |
|---|---|
| Alloy C22 Forged Fittings size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Hastelloy C22 Forged Fittings Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Hastelloy C22 Forged Fittings Types | Socketweld Fittings, Screwed-Threaded Fittings |
| ASTM B564 C22 Hastelloy Forged Fittings Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Hastelloy C22 Forged Fittings Thread | NPT, BSPT, BSPP |
| C22 Hastelloy Forged Fittings Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Nickel Alloy C22 Forged Fittings Origin & Mills | Thailand |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
Supachok Flanges, a leading supplier in Bangkok, Thailand, offers an extensive selection of Hastelloy C22 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
Hastelloy C22 flanges find their place in chemical processing, petrochemical refineries, pharmaceutical manufacturing, and marine industries, thanks to their outstanding resistance to harsh chemicals and oxidizing agents. They are perfect for piping systems, reactors, heat exchangers, and pressure vessels that come into contact with corrosive acids, chlorine, and high-temperature steam. With their durability, reliability, and resistance to corrosion and mechanical wear, Hastelloy C22 flanges are the preferred choice for applications that demand high safety standards and minimal maintenance.
| ASTM B564 / B564M | Forged Fittings and valves and parts for high temperature service. Standard Specification for Wrought Austenitic Hastelloy Forged Fittings |
| BS21 | Threading. |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| ANSI B16.11 | Forged steel fittings socket-welding and threaded. Socket Welding and Threaded Forged Fittings |
| ANSI/ASME B1.20.1 | Pipe threads, general purpose (inch). |
| ISO 4144 | Hastelloy fittings threaded to ISO 7-1. |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
Yes, we offer custom sizes for Hastelloy C22 Flanges to meet specific project needs. Our team at Supachok Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@supachokflanges.com.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Hastelloy C22 | N06022 | 2.4602 | – | NiCr21Mo14W | NW 6022 | – | – |
| Grade | C | Mo | Mn | Si | Fe | P | S | Co | Cr | W | V | Ni |
| C22 | 0.010 | 12.5 – 14.5 | 0.50 | 0.08 | 2.00 – 6.00 | 0.02 | 0.02 | 2.5 | 20 – 22.5 | 2.5 – 3.5 | 0.35 | Bal |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | Psi – 1,00,000 , MPa – 690 | 45 % |
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
