Typically made from high-quality carbon steel, alloy steel, or stainless steel, EN 1092-1 Type 13 Flanges are designed to meet the diverse needs of industrial operations. These flanges boast impressive mechanical properties, such as high tensile strength, toughness, and resistance to deformation under pressure. With their precise dimensions and smooth surface finish, they ensure a perfect fit with pipes, valves, and other equipment. Built for durability and long-lasting performance, EN 1092-1 Type 13 Flanges maintain their structural integrity even in demanding environments, providing secure connections and reducing maintenance needs in critical piping systems.
Supachok Flanges, a leading supplier in Bangkok, Thailand, offers an extensive selection of EN 1092-1 Type 13 Flanges, including weld neck flanges, slip-on flanges, blind flanges, threaded flanges, and lap joint flanges. Designed for diverse industrial applications, our high-quality inventory and commitment to exceptional service make us a trusted choice for flange products in the region.
| Size | (1/2″) To (48″) |
|---|---|
| Pressure | PN6, PN10, PN16, PN25, PN40, PN64, PN100, PN160 |
| Size Of Bore Diameter Flange | NPS ≤ 10 |
| Standard Dimensions | EN-1092, ASME B16.48, API605, BS4504, EN1092, UNI, ISO, API7S-43, ANSI/ASME B16.5, API7S-15, MSS S44, IS 2062, ASME B16.36, DIN, AWWA C207, B16.47 Series A & B, BS1560-3.1, ISO70051, API. |
| Minimum Pressure | 150# To 2500# |
| Flange Face Type Manufacturer | Raised Face, Groove And Small Tongue Groove, RTJ, Flat Face, Large Tongue & Large Male-Female And Small Male-Female, Lap-Joint Face. |
| Top Six Type Of Flange | Threaded Flange, Lap Joint Flange, Socket-Weld Flange, Blind Flange, Slip-On Flange, Weld Neck Flange |
| Standard Materials | Duplex Steel & Super Duplex Steel, Copper Nickel, Inconel, Mild Steel, Stainless Steel, Hastelloy, Alloy Steel, Carbon Steel. |
| Thickness Length | NPS ≤ 18 |
| Manufacturing Process | Forged/ Machined/ Heat Treated |
| Other Type Of Flange | Forged/ Plate/ Threaded |
| DN | GAS | Diameters | Thickness | Total | Diameter | Radius | Net | ||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Outside | bolt | bolt | Bolts | thickness | of the | weight | |||||
| circle | holes | Nr | Type | neck | |||||||
| D | K | L | C2 | H1 | d1 | R1 | Kg | ||||
| 15 | 1/2 | 80 | 55 | 11 | 4 | M10 | 12 | 20 | 30 | 4 | 0,43 |
| 20 | 3/4 | 90 | 65 | 11 | 4 | M10 | 14 | 24 | 40 | 4 | 0,66 |
| 25 | 1 | 100 | 75 | 11 | 4 | M10 | 14 | 24 | 50 | 4 | 0,82 |
| 32 | 1.1/4 | 120 | 90 | 14 | 4 | M12 | 14 | 26 | 60 | 6 | 1,17 |
| 40 | 1.1/2 | 130 | 100 | 14 | 4 | M12 | 14 | 26 | 70 | 6 | 1,4 |
| 50 | 2 | 140 | 110 | 14 | 4 | M12 | 14 | 28 | 80 | 6 | 1,59 |
| 65 | 2.1/2 | 160 | 130 | 14 | 4 | M12 | 14 | 32 | 100 | 6 | 2,17 |
| 80 | 3 | 190 | 150 | 18 | 4 | M16 | 16 | 34 | 110 | 8 | 3,2 |
| 100 | 4 | 210 | 170 | 18 | 4 | M16 | 16 | 40 | 130 | 8 | 3,59 |
| 125 | 5 | 240 | 200 | 18 | 8 | M16 | 18 | 44 | 160 | 8 | 4,94 |
| 150 | 6 | 265 | 225 | 18 | 8 | M16 | 18 | 44 | 185 | 10 | 5,83 |
| Rated Diameter | Flange | Neck | Raised face | Screws | Weight (7,85 Kg/dm3) | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| d1 | Thread | k | D | b | h1 | d3 | d4 | f | d2 | Thread | Bolt holes | KG | |
| 15 | 21,3 | R 1/2″ | 65 | 95 | 16 | 22 | 35,0 | 45,0 | 2,0 | 14 | M12 | 4 | 0,722 |
| 20 | 26,9 | R 3/4″ | 75 | 105 | 18 | 26 | 45,0 | 58,0 | 2,0 | 14 | M12 | 4 | 1,040 |
| 25 | 33,7 | R 1″ | 85 | 115 | 18 | 28 | 52,0 | 68,0 | 2,0 | 14 | M12 | 4 | 1,250 |
| 32 | 42,4 | R 1-1/4″ | 100 | 140 | 18 | 30 | 60,0 | 78,0 | 2,0 | 18 | M16 | 4 | 1,810 |
| 40 | 48,3 | R 1-1/2″ | 110 | 150 | 18 | 32 | 70,0 | 88,0 | 3,0 | 18 | M16 | 4 | 2,060 |
| 50 | 60,3 | R 2″ | 125 | 165 | 18 | 28 | 84,0 | 102,0 | 3,0 | 18 | M16 | 4 | 2,390 |
| 65 | 76,1 | R 2-1/2″ | 145 | 185 | 18 | 32 | 104,0 | 122,0 | 3,0 | 18 | M16 | 4 | 2,970 |
| 80 | 88,9 | R 3″ | 160 | 200 | 20 | 34 | 118,0 | 138,0 | 3,0 | 18 | M16 | 8 | 3,780 |
| 100 | 114,3 | R 4″ | 180 | 220 | 20 | 40 | 140,0 | 158,0 | 3,0 | 18 | M16 | 8 | 4,380 |
| 125 | 139,7 | R 5″ | 210 | 250 | 22 | 44 | 168,0 | 188,0 | 3,0 | 18 | M16 | 8 | 6,070 |
| 150 | 168,3 | R 6″ | 240 | 285 | 22 | 44 | 195,0 | 212,0 | 3,0 | 22 | M20 | 8 | 7,240 |
You’ll find EN 1092-1 Type 13 Flanges widely utilized in pipelines, pressure vessels, chemical and petrochemical plants, water treatment facilities, and oil and gas systems. They are perfect for connecting pipes, valves, pumps, and other equipment in moderate to high-pressure applications, ensuring leak-proof and secure joints. These flanges play a vital role in supporting safe, efficient, and uninterrupted operations, minimizing operational risks and maintenance demands. With their mechanical strength, corrosion resistance, and reliability, EN 1092-1 Type 13 Flanges are indispensable for critical industrial applications, delivering long-lasting performance, safety, and operational efficiency even in harsh conditions.
Yes, we offer custom sizes for EN 1092-1 Type 13 Flanges
to meet specific project needs. Our team at Supachok Flanges is committed to providing tailored solutions for all your requirements. For more details, contact us at sales@supachokflanges.com.
We are renowned for delivering products with precise, accurate dimensions. Each product undergoes thorough testing, both destructive and non-destructive, to ensure quality before being shipped to our customers.
Our team is ready to assist you. Contact us for any queries or personalized solutions.
